ASTM A36 Galvanized Serrated Welded Bar Grating Inquiry | Walkway Geometry and Load Requirements

• Type

  Grating
  Warranty

  More Than 5 Years
• Feature

  Water Resistant, Durable, Anti-Corrosion, Fire Resistant
  Shape

  Round, Oval, Square
• After-sale Service

  Online Technical Support, On-Site Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return and Replacement, Other
  Weight

  2kg
• Chemical Composition

  /
  Length

  Customized
• Alloy Or Not

  Is Alloy
  Secondary Or Not

  Non-Secondary
• Project Solution Capability

  graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
  Application

  Office Building, industrial applications, municipal construction, etc.
• Design Style

  Industrial
  Model Number

  19-W-4, 15-W-2, 30/100, 40/50, 60/100 and All
• Material

  Carbon Steelcarbon steel, Aluminum, galvanized Sheet, Other, Low Carbon Steel, Mild Steel, Stainless Steel
  Color

  Customized
• Product Name

  Steel Grating
  Standard

  GB/JIS/UK/EN/DIN
• Surface Treatment

  Hot DIP Galvanized, Painting, Self Colour / Untrea
  Grating Size

  30X100, 40X100, 30X50, 40X50 Others
• Connection

  Welded Connection,Clip Connection,Pressure Lock Connection,etc
  Sample

  Support
• Packing

  Standard Package
  Payment terms

  30%TT Advance + 70% Balance

Define bearing bar geometry and support conditions before selecting grating for a walkway.

Material and connection

The title requests A36 galvanized serrated welded grating, while the description lists several metals and connection methods. Confirm actual steel designation, serration and welded construction rather than assuming all alternatives describe the supplied panel.

Spacing and thickness

Model and spacing codes appear without complete dimension drawings. The thickness choices include broad ranges and customized entries, so identify which member they measure and specify bearing bar height, thickness and spacing.

• Actual material and surface
• Bearing bar height and thickness
• Cross bar and bearing spacing
• Panel size and support span
• Load and installation acceptance

Walkway evidence

Agree the clip or weld attachment and required tests. Durable, fire resistant and corrosion wording does not establish a fire class, tested slip resistance, allowable load or lifetime of the installed grating.
