10 Gauge Galvanized Steel Wire for Cable Making Inquiry | Hot Dip or Electro Selection
Создать QR-код
Product description
-
FunctionBaling WireSurface TreatmentGalvanised Zinc
-
Model NumberQ195Delivery Timewithin 7 days
-
Processing ServiceWelding, Bending, Punching, Decoiling, CuttingTypeRound wire
-
Zinc coating12-240g/m2Tensile Strength350-550N/mm2
-
Wire diameter0.7mm--4.0mmWeight/coil10-500kg
-
MaterialQ195/Q235/SAE1006-1008/CustomizedUsageBuilding Construction Areas
-
Galvanized TechniqueHot Dipped/ElectroPackage:Plastic Film + Hessian(woven) Bag
-
MOQ1TonProduct nameGalvaized Iron Wire
Define the cable manufacturing input wire by measured diameter and an actual material specification.
Gauge and size differences
Nine choices span 0.4–3 mm, including sizes below the described 0.7–4 mm range. Confirm 10 gauge conversion rather than assume the title represents one available diameter.
Material and coating
Q195, Q235, SAE1006–1008 or customization are listed. Hot dip and electro galvanizing are both described, requiring one chosen treatment and inspection requirement.
- Actual steel designation
- Measured wire diameter
- Galvanizing process
- Delivery mechanical condition
- Cable manufacturing criteria
Strength evidence
The stated 350–550 N/mm² tensile range and zinc range need selected material scope. Request actual records and define the downstream cable construction separately; baling function and high tensile title wording do not establish finished cable capacity.
